Products

System devices

PowerSupply

KNX PowerSupply 365

Bus voltage supply with high efficiency and small footprint. The device has an integrated bus choke and also provides an output for auxiliary voltage.

KNX PowerSupply DGS 366

Bus voltage supply with high efficiency and small footprint. It offers comprehensive diagnostics via both the integrated display and the bus. The device has a bus choke and also provides an output for auxiliary voltage.

KNX PowerSupply USB 367

Bus voltage supply with high efficiency and small footprint. It offers comprehensive diagnostics via both the integrated display and the bus. The integrated USB interface allows a connection between a PC and the KNX bus. The device has a bus choke and also provides an output for auxiliary voltage.

KNX IP LineMaster 762.1 secure

Bus voltage supply with high efficiency and integrated IP Router with support of KNX security. The device combines the essential functions of a KNX bus line: KNX power supply with choke, KNX IP router and KNX IP interface.

USB

KNX USB Interface 312

Compact USB data interface between a PC or laptop and KNX bus. The device can be used as a programming interface for the ETS® software.

KNX USB Interface Stick 332

Compact USB data interface in stick format between a PC or laptop and the KNX bus. The stick can be used as a programming interface for the ETS® software.

KNX RF USB Interface Stick 340

Compact USB data interface in stick format between a PC or laptop and the KNX RF. The stick can be used as a programming interface for the ETS® software.

KNX PowerSupply USB 367

KNX RF / ENO Push Button 440 secure

Wireless push button for KNX RF and EnOcean. With USB interface for KNX RF and KNX Data Security as well as EnOcean Security.

KNX TP Multi IO 570 (48I/O)

Universal input and output module for building control. The device offers 48 digital channels. Each channel can be used as a binary input, binary output or as a blind output. Input channels can be used to connect buttons. Output channels can directly control signal LEDs, external coupling relays or blind relays. The periphery (e.g., relay) is powered by an external power supply (24V).

KNX IP

KNX IP Interface 731

Compact programming interface for connecting a PC to the KNX bus. The connection is made via a LAN interface (IP). Power is supplied via the KNX bus.

KNX IP Interface 732 secure

Secure interface between a LAN (IP, Ethernet) and KNX and can be used as a programming interface for the ETS®. As a KNX Secure Interface (tunneling), the device prevents unauthorized access to the system. The connection between PC and interface is encrypted. The security option can be activated or deactivated in the ETS.

KNX IP Interface 740.1 wireless

The device serves as a wireless interface to the KNX bus based on WLAN. The device can be used as a programming interface for the ETS® and is a wireless alternative to USB or wired IP interfaces. The bus access via WIFI allows the installer to move freely in the building with his laptop to a large extent.

KNX IP Router 751

The compact router enables the forwarding of telegrams between different lines via a LAN (IP) as a fast backbone. The device also serves as a programming interface between a PC and the KNX bus (eg for ETS® programming).

KNX IP Router 752 secure

The device enables the secure forwarding (routing) of telegrams between different lines over a LAN (IP, Ethernet) as a fast backbone. As a secure router, the device enables the connection of unsecured communications on a KNX TP line with a secure IP backbone.

KNX IP LineMaster 762.1 secure

KNX IP BAOS 773

An interface for connecting to KNX both on telegram level (KNXnet/IP Tunneling) and on data point level (KNX Application Layer). Clients can directly access Group Objects via either a Binary Protocol (over TCP/IP or UDP/IP) or via JSON (Java Script Object Notation) Web Services.

KNX IP BAOS 774

KNX IP interfaces to the KNX bus both at the telegram level (KNXnet / IP tunneling) and at the data point level (KNX Application Layer). Thus, clients can directly access group objects via TCP / IP or UDP / IP using a binary protocol. As an alternative protocol, Java Script Object Notation (JSON) is available for use in web browsers.

KNX IP BAOS 777

Visualization and control The KNX IP BAOS 777 has an integrated web server that allows access to the visualization and device settings via a standard web browser on a PC or mobile devices such as smartphones and tablets. The web interface of the visualization allows the control of the entire KNX installation divided into the […]

KNX RF

KNX RF USB Interface Stick 340

Compact USB data interface in stick format between a PC or laptop and the KNX RF. The stick can be used as a programming interface for the ETS® software.

KNX RF / ENO Push Button 440 secure

Wireless push button for KNX RF and EnOcean. With USB interface for KNX RF and KNX Data Security as well as EnOcean Security.

KNX RF/TP Coupler 673.1 secure

Compact KNX RF/TP coupler. It connects KNX RF devices with the KNX Bus Twisted Pair. For KNX installations with ETS®. Support of KNX Data Security, Security Proxy and Segment Coupler.

Serial

KNX Serial 870

Simple integration solution for non-KNX devices. As an RS-232 interface, the device uses the proven FT1.2 protocol (PEI 10) as a telegram format.

Coupler

KNX LineCoupler 650

KNX line coupler in a compact design. It connects two KNX segments (for example a KNX line with a KNX area).

KNX LineCoupler 650.1 secure

Compact KNX line coupler with support of
KNX Security, Security Proxy and Segment Coupler. It connects two KNX segments (for example a KNX line with a KNX area).

KNX RF/TP Coupler 673.1 secure

Compact KNX RF/TP coupler. It connects KNX RF devices with the KNX Bus Twisted Pair. For KNX installations with ETS®. Support of KNX Data Security, Security Proxy and Segment Coupler.

KNX IP Router 751

KNX IP Router 752 secure

KNX IP LineMaster 762.1 secure

Gateways

EnOcean

KNX ENO 626 secure

Bidirectional, compact gateway between EnOcean radio and the KNX bus. The device supports encrypted wireless communication with EnOcean security enabled devices. More than 100 device profiles (EEP EnOcean Equipment Profile) allow simple and secure connection of different EnOcean sensors and actuators to KNX installations.

KNX ENO 636 secure

Bidirectional gateway between EnOcean radio and the KNX bus. The device supports encrypted wireless communication with EnOcean security enabled devices. More than 100 device profiles (EEP EnOcean Equipment Profile) allow simple and secure connection of different EnOcean sensors and actuators to KNX installations.

BAOS

KNX USB Interface 312

Compact USB data interface between a PC or laptop and KNX bus. The device can be used as a programming interface for the ETS® software.

KNX USB Interface Stick 332

Compact USB data interface in stick format between a PC or laptop and the KNX bus. The stick can be used as a programming interface for the ETS® software.

KNX RF USB Interface Stick 340

Compact USB data interface in stick format between a PC or laptop and the KNX RF. The stick can be used as a programming interface for the ETS® software.

KNX IP BAOS 773

KNX IP BAOS 774

KNX IP BAOS 774.1 secure

KNX IP interface to the KNX bus both at the telegram level (KNXnet / IP tunneling) and at the data point level (KNX Application Layer). Thus, clients can directly access group objects via TCP / IP or UDP / IP using a binary protocol. As an alternative protocol, Java Script Object Notation (JSON) is available for use in web browsers.

KNX IP BAOS 777

KNX BAOS Module 838 kBerry

Customer Benefits Integrated Object Server The benefit of the Object Server in the KNX BAOS Modules is the logical decoupling of the application from the KNX communication. The application can access the values of the communication objects without any knowledge of KNX telegram formats or KNX addresses used in the current installation. The KNX BAOS Module […]

KNX Serial 870

Simple integration solution for non-KNX devices. As an RS-232 interface, the device uses the proven FT1.2 protocol (PEI 10) as a telegram format.

DMX

KNX DMX-Gateway 544

Compact gateway between KNX and DMX512 with up to 64 freely configurable channels. DMX is a protocol for lighting control, especially in stage technology.

Modbus

KNX Modbus TCP Gateway 716 secure

The KNX Modbus TCP Gateway 716 is a compact Modbus interface with 250 freely configurable channels. The device enables easy integration of Modbus devices that support the TCP protocol via IP.

KNX Modbus RTU Gateway 886

The KNX Modbus RTU Gateway 886 is a compact Modbus interface with 250 freely configurable channels. The device enables easy integration of Modbus devices that support the RTU protocol via RS-485.

KNX Modbus RTU Gateway 886.1 secure

The KNX Modbus RTU Gateway 886 is a compact, bus powered
Modbus interface with 250 freely configurable channels and KNX Security. The device enables easy integration of Modbus devices that support the RTU protocol via RS-485.

Actuators, IO

Dimmer

KNX IO 530 (1D2I)

Compact 230V universal dimmer with one output and 2 binary inputs. The dimmer supports numerous functions (staircase, slumber) as well as phase and section and is suitable for all dimmable 230 V lamps (eg incandescent lamps, dimmable LED lamps, halogen lamps).

KNX IO 532 (1D1O)

Compact dimming actuator with one output for dimming LEDs with constant voltage (PWM) and one relay output. The dimming actuator may e.g. can be used for LED panels or strips. The relay output can be used to switch the LED power supply.

KNX IO 534 CV (4D)

Compact dimming actuator with 4 outputs for dimming LEDs with constant voltage (PWM). The dimming actuator may e.g. for LED panels or strips with RGB / RGBW / Tunable White configuration or as 4 independent dimming channels.

KNX IO 536 CC (4D)

Compact dimming actuator with 4 outputs for dimming LEDs with constant current.
The dimming actuator can be used e.g. for LED panels or stripes with RGB / RGBW / Tunable White configuration or as 4 independent dimmer channels.

KNX IO 546.1 secure (1D1O)

Compact dimming / switching actuator with a dimming channel for the connection of electronic ballasts (ECG) with a 0 / 1..10V interface and a relay output. The relay output can be used to switch the ECG.

KNX TP Blue IO 550 CV secure

Compact dimming actuator with 4 PWM outputs. The dimming actuator can be used e.g. for LED panels or stripes with RGB / RGBW / Tunable White configuration or as 4 independent dimmer channels.

KNX TP Blue IO 551 CC secure

Compact dimming actuator with 4 constant current dimming outputs. The dimming actuator can be used e.g. for LED panels or stripes with RGB / RGBW / Tunable White configuration or as 4 independent dimmer channels.

KNX RF Blue IO 552 CV secure

Compact dimming actuator with 4 constant voltage dimming outputs. The dimming actuator can be used e.g. for LED panels or stripes with RGB / RGBW / Tunable White configuration or as 4 independent dimmer channels.

KNX RF Blue IO 553 CC secure

Compact dimming actuator with 4 constant current control. The dimming actuator can be used e.g. for LED panels or stripes with RGB / RGBW / Tunable White configuration or as 4 independent dimmer channels.

Switch Actuator

KNX IO 510.1 secure (2O)

Compact switch actuator with 2 outputs. Functions for universal output, staircase lighting, heating actuator, etc.

KNX IO 511.1 secure (1O2I)

Compact switching actuator with one bistable output and 2 binary inputs. This device is suitable as a KNX-capable replacement for conventional impulse switches (output: lights, input 1: push button, input 2: L for zero crossing detection).

KNX IO 512 secure

The KNX switching actuator KNX IO 512 secure offers 12 bistable relay outputs that are optimised primarily for the requirements of LED lights. However, other loads can also be switched.

KNX IO 532 (1D1O)

KNX IO 546.1 secure (1D1O)

KNX TP Multi IO 570 (48I/O)

KNX IP Multi IO 580 (48I/O)

Universal input and output module for KNX IP. The device offers 48 digital channels. Each channel can be used as a binary input, binary output or as a blind output. Input channels can be used to connect buttons. Output channels can directly control signal LEDs, external coupling relays or blind relays. The periphery (e.g., relay) is powered by an external power supply (24V). The device operates using the medium KNX IP and is connected via LAN / Ethernet to the KNX installation.

Shutter Actuator

KNX IO 520 (1J2I)

Compact blinds actuator with two additional binary inputs. The device offers numerous functions including position travel over time calculation.

KNX IO 522 secure

The actuator is used to control a blind, a shutter or a window drive. The outputs are electro-mechanically locked against each other to prevent a motor defect.

KNX TP Multi IO 570 (48I/O)

KNX IP Multi IO 580 (48I/O)

Binary Input

KNX IO 410 (4I)

Compact binary input with 4 channels for controlling lights, blinds etc. The inputs can be controlled with an external voltage of 12 to 230 V.

KNX IO 411 (4Ii)

Compact binary input with 4 channels for controlling lights, blinds, etc. The inputs are suitable for dry contacts (for example pushbuttons).

KNX IO 520 (1J2I)

Compact blinds actuator with two additional binary inputs. The device offers numerous functions including position travel over time calculation.

KNX IO 530 (1D2I)

KNX TP Multi IO 570 (48I/O)

KNX IP Multi IO 580 (48I/O)

Push buttons

Pushbuttons

KNX TP Push Button Interface 420 secure

Push button interface 4-fold for KNX TP with KNX Data Security.

KNX TP Push Button 420 secure

KNX TP Push Button with integrated bus coupler and KNX Data Security.

KNX TP Push Button 420.1 secure

The KNX TP Push Button 420.1 secure with integrated bus coupling unit and room temperature controller is the new generation of our KNX push buttons in the MATCH 55 series. Both the hardware and the ETS application have been significantly improved.

24 V Push Button 436

Push button for low voltage to directly connect to push button inputs e.g. of Smarthome control panels.

KNX RF / ENO Push Button 440 secure

Wireless push button for KNX RF and EnOcean. With USB interface for KNX RF and KNX Data Security as well as EnOcean Security.
